Are you searching for a cutting-edge drilling solution that combines power, precision, and unmatched versatility? Look no further! Introducing the Hydropower Scout V, a state-of-the-art truck-mounted rig that sets new standards in the drilling industry.
Powerful Performance, Compact Design
The Hydropower Scout V boasts a compact yet robust design, making it ideal for accessing challenging job sites without compromising on performance. With its dimensions of 10.5m length, 2.5m width, and 4.3m height with the mast down, this rig easily navigates through tight spaces, ensuring efficient drilling in any location.
Reach New Depths with the KL400 Drill Head
Equipped with the high-performing KL400 Drill Head, the Hydropower Scout V achieves a maximum RPM of 1010. This cutting-edge technology delivers unparalleled drilling efficiency and accuracy, allowing you to meet your project goals with ease.
Safety, Efficiency, and Zero Energy Compliance
The Hydropower Scout V is engineered with safety and efficiency as top priorities. It is fully Zero Energy compliant, ensuring minimised environmental impact and reduced carbon footprint during operation.
Key Features:
• Winch and Wireline Limiter: Safely and precisely control drilling operations with the winch and wireline limiter, preventing accidents and enhancing overall efficiency.
• Collision Avoidance: Advanced collision avoidance technology protects both your equipment and personnel, minimising the risk of collisions during drilling activities.
• Type 4 RFID Gate Interlock: Ensure the utmost safety with the Type 4 RFID gate interlock system, preventing unauthorised access and ensuring secure operations.
• Rod Trough: Optimise drilling efficiency with the rod trough, allowing easy access to drill rods and reducing downtime.
• Driller and Offsider Platforms: Ergonomically designed platforms provide a comfortable and safe working environment for the drilling crew.
• Hydraulic Actuated Rotation Gate: Effortlessly control the rotation gate hydraulically, streamlining drilling operations and increasing productivity.
• Warning Lights and Sounds: Safety is paramount, and the rig is equipped with warning lights and sounds for all setup functions and gates, ensuring a secure working environment.
• Control Board Lockout Levers: Maintain complete control with lockout levers on all functions, enhancing safety during drilling procedures.
Unleash the Drilling Potential
The Hydropower Scout V boasts a 4.5-ton main haul winch and a 900kg wireline, making it perfect for a wide range of drilling methods, including:
• Diamond Drilling: PQ (300m), HQ (600m), NQ (800m)
• Mud Rotary: 6-inch (200m)
• Downhole Hammer: 6-inch (200m)
Versatility Meets Precision
Capable of drilling from 90 degrees to 60 degrees angles, the Hydropower Scout V adapts to various drilling applications with ease, providing unmatched versatility for your projects.
Optional In-situ Testing
Elevate your drilling capabilities with optional in-situ testing, including:
• SPT (Standard Penetration Testing)
• Shelby Tubes (U50, U63, U73, U100)
• Piston Sampling
• Packer Testing (Single or Straddled)
Experience Unrivalled Drilling Excellence
The Hydropower Scout V is your gateway to precision drilling, unmatched versatility, and outstanding performance. Upgrade your drilling operations and achieve exceptional results with this powerful truck-mounted rig.
